ONLY 2 AVAILABLE
Introducing the CUP-X1 by Sanken, a new model ultra-small cardioid microphone (φ12.7 x 59mm) with a square transducer design. Its exceptional sound quality and performance make it ideal for a wide range of applications, specifically suited for recording music instruments.
Features:
*Unique, small and slender cardioid microphone based on square transducer.
*High sound quality and performance, suitable for various applications such as music recording, speech, conference etc.
*Consistent cardioid pattern in wide frequency range, especially suitable for
*Music recording for the ideal polar pattern.
Specifications:
|
|
| Transducer |
Self - polarized condenser |
| Directivity |
Cardioid |
| Sensitivity |
-28dB (39.8mV) (0dB = 1V/Pa) |
| Equivalent noise level |
17dB SPL (A weighted) |
| Max SPL(1% THD) |
140dBSPL |
| Output impedance(1kHz ) |
140 ohms |
| Powering |
+48V ± 4V U.P.F |
| Current consumption |
4mA(typ) |
| Weight |
25g (Microphone Unit Only) |
| Dimension |
12.7mm(diameter) x 59mm |
| Surface finish |
Matte Black |
| Connector |
XLR-3-12C(M) equivalent |
| |
( 1:GND, 2:A-Hot, 3:A-Cold) |
